TIA Announces ANSI/TIA-222-H Standard, Highlights Changes

New revision of the standard expected to be published in third quarter of 2017

A revision to the ANSI/TIA-222-G standard has been unveiled, the ANSI/TIA-222-H, or “The Structural Standard for Antenna Supporting Structures and Small Wind Turbine Structures.” The new standard was constructed by TR-14 Task Group 3.

Some of the changes made to the revised standard include loading and design strength provisions to comply with changes in the national standards; and several new annexes have been added to address industry practice and requirements.

The specific changes to the standard are summarized below:

● Incorporates ASCE 7-16 Standard revised Wind maps with ultimate wind speeds based on risk category and the Wind and Ice Maps
● Update the load factors to account for the ultimate wind speeds and adds a ground elevation factor
● Enhances Section 2 (Loads) provisions including Exposure Categories based on surface roughness, more defined Risk Categories, expands topographic effects approach using three methods and adds rooftop wind speed-up factor
● Update and enhances the Seismic section 2.7 to be in conformance with ASCE 7-16 and ACI 318-14 standards and eliminates the exception for seismic loading analysis in low seismic regions
● Update Section 4 (Design Strength) requirements for changes in the Steel and Concrete Standards, AISC 360-16 & ACI 318-14, revises the Anchor Rods section and adds a new section to address U-bolts design strength
● Update Section 9 (Foundation and Anchorages) for changes to ACI 318-14 and enhances several provisions including direct embed foundations.
● Update Section 10 (Protective Grounding) provisions
● Update Section 12 (Climbing Facilities) to be in sync with other safety standards including ASSE A10.48
● Update Section 15 (Existing Structures), defines comprehensive structural analysis and feasibility study and adds the existing structures load modification factors
● Addition of new Section 16 for Mounting Systems to address their criteria
● Incorporates and enhances the Tubular Pole Base Plate from Revision G Addendum 3 as a new Annex Q and the Small Wind Turbine Structures from Revision G addendum 4 as a new Section 17
● Addition of new annexes for Wind Induced Structural Oscillations (Annex M), New Tower Construction (Annex N), Existing Tower Modification Inspection (Annex O) and Tubular Pole Weld Toe Crack Evaluation (Annex P)
● Updates to the other sections and annexes to reflect changes in the main sections of standard

The final draft of the ANSI/TIA-222-H is expected to go out to a committee for a vote in January or February 2017. The revised standard is expected to be published sometime in the third quarter of 2017.
