Lawo Power Core MAX is a new version of the Power Core AoIP mixing engine that can support multiple physical or virtual mixing surfaces — two, three, or even four mixing interfaces per engine, depending on mixing requirements.
Power Core has 96 available DSP channels, 80 summing busses, an internal 1,920 x 1,920 routing matrix, plus 128 dual-redundant MADI channels and 128 AES67/Ravenna channels, standard.
Operators can use the eight rear-channel I/O expansion slots to accommodate more analog, digital, AES67 and Dante audio signals. There’s also ST2022-7 Seamless Protection Switching for dual-redundant AoIP network connections, and ST2110-30 compliance for seamless interoperability of audio and video equipment in combined radio / TV broadcast plants.
Lawo says that these capabilities, plus the ability to connect to as many as four independent Ruby mixing surfaces, makes Power Core MAX perfect for large multi-studio projects. In addition, broadcasters with medium-size or smaller facilities can use it as an I/O gateway and mixing engine for an entire radio station.
