IBC Sneak Peek: Elber Showcases Latest Gear

Will highlight range of products for radio applications

At IBC2019 Elber will showcase the Wayber II analog FM/digital (QPSK, 16-64QAM) microwave link, together with the state-of-the-art SIGNUM IRD.

Able to transport L+R, AES-EBU, MPX and SCA signals, the company says the Wayber II offers quality performance both in signal processing and microwave applications.

The front panel is fitted with a 3.5-inch TFT touchscreen, an Ethernet management port, a USB connector for customer authenti­cation and firmware upgrades, as well as LEDs for immediate information about equipment sta­tus.

The back panel hosts all I/O connectors for both baseband and RF signals. If inputs are left- and right-channel, the transmitter can also act as a stereo encoder, generating the MPX signal adding SCA sub­carriers or (optionally) creating RDS data through the UECP protocol over a RS-232 interface.

Elber’s Signum it is a compact and reliable IRD [Integrated Receiver Decoder] designed for the high-end Radio distribution market.

According to the company, the system demodulates one or two DVB-S/ S2 signals up to 32APSK (single/multi-stream), achieving 256 KS/s as minimum symbol rate. The TS demodulated signals can be aligned and configured in 1+1 switching for redundancy. Redundancy can also be achieved with external ASI and TSoIP inputs.

Signum supports MPEG-1 LI/II audio codec, providing analog and digital outputs. In addition, users can set a data PID to be decoded and passed to the internal RDS encoder, generating the dual MPX FM output.

Elber says the EDI interface means Signum is a suitable solution to feed transmitters in DAB/DAB+ environments. It also supports BISS 0/1/E descrambling.

IBC Stand: 8.D35
